320nm激光器| Wavelength (nm) | 320± 1 |
| Operating mode | CW |
| Output power (mW) | 1-20 |
| Power stability (rms, over 4 hours) | <5%, <3% |
| Transverse mode | TEM00 |
| M2 factor | < 1.5 |
| Beam diameter at the aperture ( 1/e2, mm) | <0.5 |
| Beam divergence, full angle (mrad) | <2.5 |
| Polarization Ratio | >50:1, (Horizontal or Vertical Optional) |
| Warm-up time (minutes) | < 10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating Temperature (°C) | 10-35 |
| Modulation option | TTL on/off, 1Hz- 1kHz, 1kHz- 10kHz, |
| Power supply (90-264VAC) | PSU-H-LED/ |
| Warranty | 1 year |
