604nm激光器

产品说明：604nm激光器 LL604-100mw LD PUMPED ALL-SOLID-STATE RED LASER AT 604nm Red laser at 604nm is made features of TEM00 long lifetime and easy operating which is widely used in measurement spectrum analysis as the substitute for He-Ne laser

订购热线：0431-81759561

产品详细

604nm激光器
LL604-100mw

LD PUMPED ALL-SOLID-STATE RED LASER AT 604nm Red laser at 604nm is made features of TEM00, long lifetime and easy operating, which is widely used in measurement, spectrum analysis as the substitute for He-Ne lasers.

Wavelength (nm)	604±3
Operating mode	CW
Output power (mW)	> 1, 10, 20, … , 100
Power stability (rms, over 4 hours)	<3%, <5%, < 10%
Transverse mode	Near TEM00
Dimensions of beam at the aperture (mm)	~ 1.0
Beam divergence, full angle (mrad)	<1.5
Warm-up time (minutes)	<5
Beam height from base plate (mm)	27.4
Operating temperature (C)	10~35
Power supply (90-264VAC)	PSU-H-FDA
Expected lifetime (hours)	10000
Warranty	1 year
